Print mode
Thermal sensitive
-
Resolving power
203dpi
-
Maximum printing speed
100mm/s
-
Print width range
Max 48mm
-
Print length
25-175mm (removing watermark function can reach 300mm)
-
Support paper types
Roll paper
-
Width
25-58mm
-
Outer diameter of paper roll
≤80mm
-
Medium thickness
0.08-0.2mm
-
Processor
32-bit RISCCPU
-
Storage
RAM:2MB FLASH:8MB
-
Communication interface
USB(Optional:Bluetooth, Wi-Fi)
-
Electrical parameters
DC9V,2A
-
Print head brand
ROHM
-
Movement lifespan
50KM
-
Sensor type
Paper shortage, label stitching, cover opening, print head temperature
-
Instruction set
TSPL、ESC
-
Print contents
English, Simplified Chinese, Traditional Chinese, Images, Characters, Lines, Symbols, 1D Barcodes, 2D Barcodes
-
Encoding method
GBK,BIG5,KSC5601,UTF-8(vector font)
-
Font type
Song style
-
Font size
ASCIl Font A:12*24,ASC Font B: 9*17, Chinese characters 24 * 24
-
One-dimensional code
EAN128，CODE128，CODE25，CODE39，CODE93，EAN13,，EAN
13+2，EAN13-5，CODABAR，POST，UPCA，UPCA+2，UPCA+5，UP
CE+2，UPCE+5，PLESSEY，ITF14，EAN14
-
QR code
QRCODE,DataMatrix
-
Graphical
Support bitmap of different densities and download and print bitmap (maximum size of each bitmap is 64K, total size of bitmap is 256K)
-
System support platform
Android
-
Docking platform
platforms such as tomato tags, courier assistants, and Fenghuo delivery
-
Firmware upgrade method
Support USB local upgrade and OTA upgrade
-
Device log retrieval
Not currently supported
-
Equipment status reporting
feasible
-
Homework status reporting
feasible
-
Paper cutting method
Manual paper tearing
-
Opening method
Flip up the cover
-
Paper warehouse form
Paper bin diameter 80mm
-
Paper output method
Take out the paper
-
Appearance size (Length * Width * Height)
160*120*122mm
-
Packaging size
198*180*140mm
-
Bare Weight
420g(including battery/adapter)
-
Weight of a single machine
0.78Kg
-
Parts
Power adapter, data cable, instruction
manual (including warranty card)
-
Number of units
12 units/box
-
Key
Open lid button * 1, paper feed button * 1
-
Voice prompt
Buzzer
-
Working temperature/humidity
0℃-40℃, 30%-80%RH
-
Storage temperature/humidity
-40℃-60℃, 5%-95%RH
-
Paper rollback
Support (short distance)
-
Auto feed
Feasible
-
Certification standards
CCC certification
-
ESD requirements
Contact discharge: Soil 4KV Air discharge: Soil 8KV
